SLS460 Mini Skid Steer Loader
|
Item |
Metric |
Inch |
|
Max working height |
2420 mm |
95.3 inch |
|
Max pin height |
2099 mm |
82.7 inch |
|
Max dump height |
1617 mm |
63.7 inch |
|
The highest point discharge distance |
615 mm |
24.2 inch |
|
Bucket swing angle |
79° |
79° |
|
Bucket unloading angle |
36° |
36° |
|
Opening-closing angle |
43° |
43° |
|
Angle of departure |
30° |
30° |
|
Total height |
1607 mm |
63.3 inch |
|
The height from the ground |
300 mm |
11.8 inch |
|
Wheelbase |
1065 mm |
41.9 inch |
|
No bucket length |
2200 mm |
86.6 inch |
|
Total width 1033 |
1033 mm |
40.7 inch |
|
Bucket width |
1140 mm |
44.9inch |
|
Total length（L）（with bucket） |
2752 mm |
108.4 inch |
|
Turning radius (R) |
2198 mm |
86.5 inch |
Main performance parameters:
|
Engine |
Model |
D1105-EF02 |
|||||
|
Rated power |
18.2KW/25HP |
||||||
|
Rotating speed（rpm） |
3000 |
||||||
|
Noise（Db） |
≤95 |
||||||
|
Hydraulic System |
Hydraulic pressure（Mpa） |
20 |
|||||
|
Cycle time（s） |
Raise |
Dump |
Lower |
||||
|
3.89 |
1.6 |
3.35 |
|||||
|
Performance parameters |
|
Metric |
inch |
||||
|
Load weight (kg) |
300 Kg |
667 Lb |
|||||
|
Bucket capacity |
0.14 m3 |
4.95 ft3 |
|||||
|
Max lifting power |
1258Kg |
2795.6 Lb |
|||||
|
speed |
0-8Km/h |
0-4.972mlie/h |
|||||
|
Operating weight |
1775kg
|
3944lb
|
|||||
|
Main pump |
Qty: 2+1 |
||||||
|
Flow of main pump |
67.2L/min |
||||||
|
Valve |
Qty :2 |
||||||
